Description
We offer delivery all over Australia. Freight will be quoted after you have placed your order.
YES – You can cancel your order if not happy with freight cost.
IMPORTANT:Â You are ordering from a manufacturer. So there is a build time.
Please review order dates below, this will let you know when your order will be available for pickup/delivery.
 Order Dates Quick Link: https://aohmanufacturing.com/order-dates/
If you are just getting a unit for yourself, and not for resale you are welcome to order just be aware of the manufacturing time.
12 Month Warranty.
Standard Unit Below, However all specifications are can be custom to suit your requirements & certifications.
Simply notify us of any build change requirements after we issue your build welcome pack.
Product Details
|
Product name
|
foldable container house
|
|
External dimensions
|
L5800mm * W2500mm * H2450mm
|
|
Internal dimensions
|
L5650mm * W2350mm * H2230mm
|
|
Folding size
|
L5800mm W2500mm H440mm
|
|
Weight
|
1.3T
|
|
Roof load
|
≧50kilograms/m2
|
|
looring load
|
≧150kilograms/m2
|
|
Aisle load
|
≧200kilograms/m2
|
|
Wall side stress
|
≧80kilograms/m2
|
|
Wall deformation coefficient
|
≧300kilograms/m2
|
|
Seismic grade
|
10-magnitude
|
|
Wind loading
|
11 level of wind loading
|
|
Fire proof
|
A grade
|
|
Top girder
|
Special shaped steel galvanized concave convex pipe 63mm*80mm*1.5mm（both sides）
|
|
Bottom girder
|
Special shaped steel galvanized concave convex pipe 63mm*160mm*2.0mm（both sides）
|
|
Top beam
|
Galvanized square pipe 50mm*50mm*1.8mm
|
|
Front and rear end girder
|
Special shaped steel galvanized concave convex pipe 63mm*80mm*1.5（both sides）
|
|
Sidewall frame
|
Special shaped steel galvanized concave convex pipe 63mm*80mm*1.5（both sides）
|
|
Bottom crossbeam
|
Galvanized square steel pipe 40mm*80mm*2.0mm”
|
|
Folding hinge
|
Galvanized hinge 85mm*115mm*3mm（Shaft column304stainless steel）
|
|
Floor
|
Grade A fireproof glass magnesium plate（15mm）
|
|
Wall panel
|
Heat insulation rock wool color steel composite sandwich panel 0.326mm color steel plate / 50mm / 75mm
|
|
Window
|
Aluminum alloy anti-theft integrated window (push-pull Series) 950mm*1200mm(With screen window)
|
|
Security door
|
Special anti-theft door for folding container” 860mm*1980mm
|
|
Electrical system
|
Circuit protector，Industrial plug and socket ，Single tube LED light，
Special socket for air conditioner，Light switch，lamp |
|
Customized service
|
Can be customized according to customer needs
|
